tooltips, current snapshot 15-Jan-08 🔗 link

Still hoping this could be fixed soon?  Having to scroll the bb2 page for
hosts with long descriptions like contact and vendor info is a pain.  I
still do not really understand why this is only a problem on the bb2 page.


~David


From: Gore, David W (David) [mailto:user-3e5761c68b56@xymon.invalid]
Sent: Thursday, November 15, 2007 14:20
To: user-ae9b8668bcde@xymon.invalid
Subject: RE: [hobbit] tooltips


In regards to the hobbit snapshot:

They say a picture is worth a thousand words.  If the list server allows it,
I have attached an image of my bb2.html page.  bb2 is our primary view and,
as you can see from the image, tooltips pushes all the hobbit columns out of
the view to the right.

Tooltips are the text you see when you hover over items like the smiley's in
hobbit?  I suppose it has always worked well for the little smiley gif
icons, just not so well for the bb2 host links where it seems to add the
tooltip to the hostname rather than create floating text.

~David


From: Johann Eggers [mailto:user-769b09132207@xymon.invalid]
Sent: Thursday, November 15, 2007 13:11
To: user-ae9b8668bcde@xymon.invalid
Subject: [hobbit] tooltips


Re: the tooltips issue:


Isn't it useful to make this an option whether they should be displayed on
the bb2 page or not?


I really like the tooltips but I agree with David that they will clutter
your bb2 page so that this page is not longer usable.


Johann


From: Gore, David W (David) [mailto:user-3e5761c68b56@xymon.invalid]
Sent: Donnerstag, 15. November 2007 13:47
To: user-ae9b8668bcde@xymon.invalid
Subject: RE: [hobbit] stale alerts


I am running 4.2.0 with the allinone patch.  I do have a suspicion that
external server side scripts could contribute to the stale alerts.  In my
case, specifically a script that ssh's to a remote host and executes a shell
script on the remote host.  It may also happen in conjunction with these
errors in the logs, which someone else recently reported:


page.log.1:2007-11-05 16:20:53 hobbitd_alert: Got message 14425, expected
14424

As soon as the issue with tooltips is resolved, I will be moving our primary
hobbit to the snapshot release.


The snapshot, seems much
better, but with tooltips and host descriptions pushing our display to
the far right of the screen we cannot use it right now.

~David

On Tue, Jan 15, 2008 at 10:52:37PM +0000, David Gore wrote:

Sorry this has taken much too long. The attached patch will make
"--tooltips=always" (or =never, if you so prefer) work on the BB2
page also.

Goes on top of any recent snapshot.


Regards,
Henrik

Henrik Stoerner wrote:

I applied this patch and use '--tooltips=never', but the issue still remains.  Anyone else have success?  We are using snapshot 4.3.0-0.20080103, which is older and might be the cause for the failure.

Tom

On Thu, Mar 27, 2008 at 08:59:41AM -0400, Tom Georgoulias wrote:

Ok, then please refresh my memory: What commandline options do you use
for bbgen, what pages end up having tooltips (i.e. the COMMENT text
only shows up in a tooltip), and what pages end up having the COMMENT text next to the hostname ?


Regards,
Henrik

Henrik Stoerner wrote:

Here is my command line (others may have something different):

[bbdisplay]
  <snip>
         CMD bbgen $BBGENOPTS --report --tooltips=never --rss --rsslimit=red --nopropyellow=dbmaint

The info column page has the tooltips displayed the way I would expect them to.

The DESCR and COMMENT info is displayed next to the hostname on bb2.html.

If needed, I can send you a screenshot to help visualize.

Thanks,
Tom

Hi,

Henrik Stoerner wrote:

I just applied the patch to the latest snapshot. The problem has been resolved. I start bbgen with "--tooltips=never" and they really disappered.

But, unfortunately, the problem with wrong msgs, ports, and files still persists. When I klick on the msgs icon of host ynode8, for example, I get the following output:
No entries in /var/log/messages

No entries in /var/log/messages


Full log /var/log/messages
Mar 27 16:16:13 ynode6 kernel: ...
Mar 27 16:20:02 ynode6 ...
Mar 27 16:30:02 ynode6 ...


Full log /var/log/messages
Cannot open logfile /var/log/messages : Permission denied

Full log /var/adm/messages

Full log /var/adm/messages
Mar 27 16:18:03 ossun1 sshd...
Mar 27 16:23:03 ossun1 sshd...


As you can see, the output is totally messed and contains messages from other hosts. Hobbit also suddenly complains that no port checks were defined, although the host never checked for ports.

--
Regards,

Dirk Kastens
Universitaet Osnabrueck, Rechenzentrum (Computer Center)
Albrechtstr. 28, 49069 Osnabrueck, Germany
Tel.: +XX-XXX-XXX-XXXX, FAX: -2470

On Thu, Mar 27, 2008 at 11:37:53AM -0400, Tom Georgoulias wrote:

Please do, I cannot figure out what you're seeing versus what you're
expecting.


Regards,
Henrik

On Thu, Mar 27, 2008 at 04:57:19PM +0100, Dirk Kastens wrote:

I seem to recall that your first report mentioned that this started
happening when you started using the BBWin client in centralized mode ?

A quick test for this would be to simply delete line 1920 of
hobbitd/hobbitd_client.c (in the current snapshot) - the one that calls
the bbwin parser:

	handle_win32_bbwin_client(hostname, clientclass, ......

If rebuilding hobbitd_client without that function makes the issue
disappear, then that is where I should look.


Another thing you could try for me, please: Run the hobbitd_client
module through the Valgrind memory checker - this is only possible
if your Hobbit server is Intel-based, though. Some linux distros include
the "valgrind" package, but if not then you can download it from
valgrind.org

With valgrind installed, change hobbitlaunch.cfg (the [clientdata]
section), so the CMD setting becomes
	CMD hobbitd_channel --channel=client --log=$BBSERVERLOGS/clientdata.log \
		valgrind --log-file=/tmp/hclient.log hobbitd_client
i.e. insert the "valgrind --log-file..." stuff right before
hobbitd_client.

When hobbitd_client now runs, valgrind will log memory access problems
to a /tmp/hclient.log.PID file. It would be interesting to see if
it catches anything.


Regards,
Henrik

Hendrik,

That wasn't me. It started with one of the snapshots from February. I
went back to a snapshot from last year and the problem disappeared.

The valgrind package is installed. Let's wait for some output...

--
Regards,

Dirk Kastens
Universitaet Osnabrueck, Rechenzentrum (Computer Center)
Albrechtstr. 28, 49069 Osnabrueck, Germany
Tel.: +XX-XXX-XXX-XXXX, FAX: -2470

Hi Dirk,

seems I have this problem also, which should make it easier to debug. I
have an idea where the problem is - stay tuned ...


Henrik

On Fri, Mar 28, 2008 at 09:09:46AM +0100, Dirk Kastens wrote:

On Thu, Mar 27, 2008 at 04:57:19PM +0100, Dirk Kastens wrote:

I just committed a patch that should fix this, it is in the snapshot available now at http://www.hswn.dk/beta/

Let me know if it is still a problem.


Regards,
Henrik

Henrik,

That looks fantastic!  I had actually spent way too much time on this
and had reduced my bb-hosts from 1800 lines to a dozen lines hoping to
isolate the problem, in addition to turning down all the checks in
hobbit-clients.cfg and client-local.cfg.
If you were wondering, the msgs, ports, and files problems were what
were causing those repeated (two at a time) cores of hobbitd_client, and
why we saw the valgrind output all over the place.  There have not been
any cores since I started using the current snapshot.  Although, I only
have a fraction of my hosts running, there have been no cores for more
than 8 hours.
I am going to start turning up the full load of hosts.

David Gore (v965-3670) Network Management Systems (NMS) IMPACT Transport Team Lead - SCSA, SCNA Page: 1-800-PAG-eMCI pin 1406090 Vnet: 965-3676

Hi Henrik,

Just installed the latest snapshot. The problem disappeared :-)
Thanks very much for the support.

--
Regards,

Dirk Kastens
Universitaet Osnabrueck, Rechenzentrum (Computer Center)
Albrechtstr. 28, 49069 Osnabrueck, Germany
Tel.: +XX-XXX-XXX-XXXX, FAX: -2470
