filesystem check with multiple disk monitors 🔗 link

Howdy

I am a user from bigbrother days.  In bigbrother I cloned/customized the filesystem check script to allow me to have more than one disk column. I usually had columns for disk_sys (OS) , disk_dba (dbase) and disk_app (application). This allowed me to wake the other people (app/dba) when it was their disk problem, a problem I was not going to touch anyway. In BB the script ran on the remote/client machine. Now here in xymon I see disk is part of the data pulled for each client and parsed on the server. I can (and have) written a test to run on the client and send the status back up to xymon - the old BB way. I was wondering if there was enough interest in above functionality for me to make the effort to include it in the server side parse code.


I have already looked into this and got a not-pretty-code version working with this expended config in analysis

the FST (three chars) is appended to disk so below config will give extra columns       disk_dba disk_ard in addition to just disk.   You can make as many extras as you want.

Just disk got everything not put anywhere else ... being paranoid about losing newly added filesystems, there must be a 'everything else' column.
HOST=dbasserverone
        DISK %^/ip|du|vd|hq|sp|st|hd|iq|dc|id|ht|dt|hp|dd|dq... FST=dba 100 101
        DISK %^/[a-z][a-z][0-9][0-9][0-9] FST=dba 100 101
        DISK %^/dp... FST=dba 93 95
        DISK %^/redo..|arc.. FST=ard 90 95


In the screenshot the entries with disk_sys is actually the clients running the old BB way.  "Everything else" is in disk_sys. For these  I could hide the disk column, which is the column/monitor that the server is generating. I just did not do the hide step.
This is a test setup, we are evaluating moving to Xymon. I found no commercial product that can do multiple filesystem checks the way I want, but I could make Xymon do it. Yeah open source!


-- Bakkies

Looks good.  Also this: http://www.xymonton.org/monitors:fs-test

This dynamically creates and removes "fs_<partition>" test dots for the
various filesystems (eg "fs_root", "fs_home", "fs_usr").  Long names are
converted to index numbers such as "fs_3" for the third filesystem listed.
 Each dot can be separately disabled or alerted as desired.  Typically runs
on the Xymon server and automatically gets what it needs by querying the
server via xymon calls, so no configuration required apart from tasks.cfg.

On 28 February 2013 02:58, Bakkies Gatvol <user-66e2e196cd54@xymon.invalid> wrote:

Thanks!   I will look at this - maybe a different/better way to do it. I have 70+ disks so dots across the screen is not practical.

G

From: user-71895fb2e44c@xymon.invalid Date: Thu, 28 Feb 2013 17:04:57 +1100 Subject: Re: [Xymon] filesystem check with multiple disk monitors To: user-66e2e196cd54@xymon.invalid CC: xymon at xymon.com  Looks good.  Also this: http://www.xymonton.org/monitors:fs-test  This dynamically creates and removes "fs_<partition>" test dots for the  various filesystems (eg "fs_root", "fs_home", "fs_usr").  Long names  are converted to index numbers such as "fs_3" for the third filesystem  listed.  Each dot can be separately disabled or alerted as desired.    Typically runs on the Xymon server and automatically gets what it  needs by querying the server via xymon calls, so no configuration  required apart from tasks.cfg.   On 28 February 2013 02:58, Bakkies Gatvol  <user-66e2e196cd54@xymon.invalid<mailto:user-66e2e196cd54@xymon.invalid>> wrote:  Howdy  I am a user from bigbrother days.  In bigbrother I cloned/customized  the filesystem check script to allow me to have more than one disk  column. I usually had columns for disk_sys (OS) , disk_dba (dbase) and  disk_app (application). This allowed me to wake the other people  (app/dba) when it was their disk problem, a problem I was not going to  touch anyway. In BB the script ran on the remote/client machine. Now  here in xymon I see disk is part of the data pulled for each client and  parsed on the server. I can (and have) written a test to run on the  client and send the status back up to xymon - the old BB way. I was  wondering if there was enough interest in above functionality for me to  make the effort to include it in the server side parse code.   I have already looked into this and got a not-pretty-code version  working with this expended config in analysis  the FST (three chars) is appended to disk so below config will give  extra columns        disk_dba disk_ard in addition to just disk.   You can make as many extras as you want.  Just disk got everything not put anywhere else ... being paranoid about  losing newly added filesystems, there must be a 'everything else'  column.  HOST=dbasserverone          DISK %^/ip|du|vd|hq|sp|st|hd|iq|dc|id|ht|dt|hp|dd|dq... FST=dba  100 101          DISK %^/[a-z][a-z][0-9][0-9][0-9] FST=dba 100 101          DISK %^/dp... FST=dba 93 95          DISK %^/redo..|arc.. FST=ard 90 95   In the screenshot the entries with disk_sys is actually the clients  running the old BB way.  "Everything else" is in disk_sys. For these  I  could hide the disk column, which is the column/monitor that the server  is generating. I just did not do the hide step.  This is a test setup, we are evaluating moving to Xymon. I found no  commercial product that can do multiple filesystem checks the way I  want, but I could make Xymon do it. Yeah open source!    -- Bakkies

On 1 March 2013 00:52, Bakkies Gatvol <user-66e2e196cd54@xymon.invalid> wrote:

70 disks!  Yikes.  Maybe you could use a separate page for disks only!
 Might be able to do this with group-only and group-except?

J
