Problem with "TITLE exec:" in hobbitgraph.cfg

2 messages in this thread

list wally.nl · Tue, 31 Mar 2009 11:46:52 +0200 (CEST) ·
I'm having trouble getting "TITLE exec:" working (currently running xymon
4.2.3 on debian lenny). The hobbitgraph.cfg snippet:

[mrtg]
    ..
    TITLE exec:/usr/local/hobbit/bin/lun-title.sh
    ..
    ..

the file /usr/local/hobbit/bin/lun-title.sh:

-rwxr-xr-x 1 hobbit hobbit    395 2009-03-30 11:46 lun-title.sh

------------<cut>------------
#!/bin/sh

HOSTNAME="$1"; shift
GTYPE="$1"; shift
LEGEND="$1"; shift
RRD="$1"; shift

echo "RRD=$RRD, rest is $*" >>/tmp/title.log

MRTGSET="`echo $RRD | sed -e's/\.rrd$//'`"
echo "MRTGSET=$MRTGSET" >>/tmp/title.log

# MRTGTITLE=`grep -i "Title\[$MRTGSET\]:" /etc/lun-title.cfg | cut -d: -f2-`
MRTGTITLE="IOPS per lun"
echo "TITLE=$MRTGTITLE" >>/tmp/title.log

echo "$MRTGTITLE $LEGEND"
exit 0
------------<cut>------------

So the title should (at the moment) always be "IOPS per lun" but I've got
the feeling that the script isn't even executed since it isn't logging to
the /tmp/title.log file. I can't find anything wrong in /var/log/xymon/*
files.

The graph itself works fine but the title is random 'crap' with every
refresh (see attached example).

Any help would be appreciated
Attachments (1)
list Lukas Kohl · Mon, 2 Dec 2013 11:22:34 +0100 ·
Hello,
I am facing the exact same Problem with the TITLE exec: Parameter.
Server and Clients are running RHEL 6.4 with Xymon 4.3.7.

I am astonished, because the crappy Titles appear as soon as I set TITLE
exec: even, when the script doesn't exist, or when I don't set a Script at
all.
I tried a Perl and a Bash Script, both without success.


Kind regards,
Lukas
